Plate Heat Exchanger TSC 2611
Max Flow Rate: 40 m³/h (DN50) – 50 m³/h (DN65)
Plates Material: Stainless steel AISI 304 – AISI 316
Gaskets: NBR, EPDM, FKM
Energy Recovery: Up to 90%
Product Overview:
The TSC 2611 from Technosystem is a compact yet powerful gasketed plate heat exchanger with a stainless steel frame and corrugated plates for superior thermal efficiency. Its design allows fast inspection, easy cleaning, and future expansion by adding more plates.
Built and tested to PED standards, it is ideal for industries where hygiene, performance, and flexibility are essential — especially in food and beverage processing.
Technical Specifications TSC 2611:
| Feature | Description |
|---|---|
| Applications | Heating, cooling, steam, food fluids & oils |
| Max flow rate | 40 m³/h (DN50) – 50 m³/h (DN65) |
| Max number of plates | 209 |
| Chassis | PN6, PN10 (PN16 on request) |
| Frame material | Stainless steel AISI 304L or AISI 316L |
| Plate material | Stainless steel AISI 304 or AISI 316, Titanium, SMO 254 alloy |
| Gasket materials | NBR, EPDM, FKM (FDA approved) |
| Connection materials | Stainless steel ASTM A193 B8 or B8M |
Applications:
- Heating & Cooling of process fluids
- Steam-based heating operations
- Food and beverage pasteurization
- Processing of food fluids and edible oils
- General industrial thermal exchange applications
Key Advantages:
- Fully stainless steel frame – corrosion resistance & hygiene compliance
- FDA-approved gasket options for direct food contact
- Expandable design – add plates up to 209 for future capacity needs
- Easy maintenance – quick opening for cleaning without special tools
- Compliant & Proven – PED-certified manufacturing for safety & reliability
FAQ:
Q: Is the TSC 2611 suitable for pasteurization?
Yes — it is specifically designed for pasteurizing food fluids while preserving product quality.
Q: Can it be used with steam?
Absolutely — it is fully compatible with steam heating applications.
Q: How easy is it to clean?
The gasketed design allows quick opening and plate removal for cleaning and inspection.
Q: What materials are available for plates?
Options include AISI 304, AISI 316, Titanium, and Alloy SMO 254.
Purchase & Pricing:
The Technosystem TSC 2611 is available with multiple custom configurations:
- Flow rate options
- Plate materials and gasket choices
- Pressure ratings (PN6, PN10, PN16 on request)
Pricing depends on selected specifications and required accessories.
Contact Vira Trading Group for an exact quotation and delivery schedule based on your project needs.
